SFP+ Ports:12 x 1/10G
RJ-45 : 4 x 10/100/1000
Switching Capacity: 248Gbps
Forward Rate: 184.512Mpps
MAC Address Table: 32K
32Mb Packet Buffer
Supports 10K Jumbo Frames
Wirespeed forwarding
IPv4/IPv6 Dual Protocol Stack
Port Isolation
Storm Control
Broadcast/Multicast/Unknown Storm Control
Up to 512 Access Control Lists (ACL) based on L2/L3/L4
Port Security
MAC Authentication
Dynamic ARP Inspection
AAA (IEEE 802.1X RADIUS/TACACS+)
IP Source Guard
DHCP Snooping
Encrypt switch access with SSH and SSL
Static routes
DHCP v4/v6 Client / DHCP Relay / DHCP Server
SFP ports support 802.3z (1000SX/LX/LHX/ZX) and 802.ae (10GBase)
IEEE 802.3x Flow Control
Spanning Tree:
IEEE 802.1D Spanning Tree Protocol (STP),
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP),
IEEE 802.1s Multiple Rapid Spanning Tree Protocol
(MSTP,64 instances)
BPDU Filter/Guard
BPDU Forward
Root Guard
Up to 4094 IEEE 802.1Q (802.3ac) VLANs:
Port-Based/MAC-Based/Protocol-Based(IEEE 802.1v)
Guest VLAN
Auto Voice VLAN
Dynamic VLAN Assignment
802.3ad Link Aggregation (static and LACP)
Multicast:
IGMP v1/v2/v3 snooping
IGMP Filtering/Throttling:
IGMP Queries
IGMP Immediate leave
MLD Snooping
IEEE 802.1AB LLDP/LLDP-MED
IEEE 802.3az Energy Efficient Ethernet
ITU-T G.8032v2/Y.1344 – Ethernet Ring Protection Switching (ERPSv2)
Web-based Graphical User Interface (GUI)
Industry-standard CLI (Telnet/SSH) with context-sensitive help
Console management port on the front panel for ease of access
Comprehensive SNMP MIB support for standards based device
management
Dual Image/Configuration
RMON (groups 1,2,3 and 9)
NTP
IEEE 1588v2 Precision Time Protocol (PTP)
SNMP v1/v2/v3
Rate Limiting (Ingress/Egress Port-Based)
Priority Queues Schedule (WRR/Strict Priority/Hybrid QoS)
Port-Based QoS
IPv4/IPv6 DSCP
DiffServ
Auto VOIP
8 HW Queues per port for 802.1p priority tagging
Cable Test
Digital Diagnostic Monitoring (DDM) on SFP Ports
Ping polling for IPv4 and IPv6
TraceRoute for IPv4 and IPv6
Port Mirror (Many to One)
Event/Error Log/Syslog/SMTP Alerts
SFlow
Max Power Consumption: 26W
Power Supply AC Input: 100 – 240 V AC, 50/60 Hz
Dimensions: 13″W x 8.3″D x 1.7″H (33cm x 21cm x 4.4cm)
19 in rack mounting hardware included
Weight: 5.32lb (2.41 kg)
Operating Temperature: 32 to 122°F (0 to 50°C)
Storage Temperature: -40 to 158°F (-40 to 70°C)
Operating/Storage Humidity: 10 to 90% (non-condensing)
Emissions: CE Mark: EN 55022, Class A; FCC Part 15 Class A
Immunity: IEC 61000-3-3, 61000-4-2/3/4/5/6/8
Five years (Including power supply)
