High-Density Optical Fiber Panels

High-Density Optical Fiber Panels

OVERVIEW

Signamax offers a range of economy optical fiber patch panels for ST, SC, and LC connections. These rack-mount panels are available in 24- and 48-port (24-, 48-, and 96-fiber) sizes based on standard Signamax optical fiber keystone jacks and are ideal where space is limited as compared to the standard-density optical fiber panels or enclosures. These high-density panels provide increased termi-nation density due to more compact adapter population. High-density panels are equipped with rear cable management bar when there is a need to provide support for bulky cables and/or maintain required cable bend radii.

KEY FEATURES

  • ST, SC, and LC connections
  • Available in 24- and 48-port (24-, 48-, and 96-fiber) sizes
  • Based on standard Signamax optical fiber keystone jacks
  • Equipped with rear cable management bar

SPECIFICATIONS

Information will be available soon.

DOWNLOADS

Information will be available soon

ORDERING INFORMATION

ST Optical Fiber Panel

Part Number Description
24HDST-FT 24-Fiber High-Density ST MM Panel, 1.75"H
48HDST-FT 48-Fiber High-Density ST MM Panel, 3.50"H





SC Optical Fiber Panels

Part Number Description
24HDSC-FT 24-Fiber (24-Simplex) High-Density SC MM Panel, 1.75"H
48HDSC-FT 48-Fiber (48-Simplex) High-Density SC MM Panel, 3.50"H





LC Optical Fiber Panels

Part Number Description
24HDLC-FT 48-Fiber (24-Duplex) High-Density LC MM Panel, 1.75"H
48HDLC-FT 96-Fiber (48-Duplex) High-Density LC MM Panel, 3.50"H
